Garage doors

Sectional garage doors are used in construction of detached and multi-family buildings. The individual preferences of our customers are reflected by our personalized products manufactured on order. Selected colours of high-quality door panels and a wide selection of laminates of external doors allow you to create well composed colour sets that will become a showcase of the house.

For convenience of use, garage doors can be equipped with an automatic drive. Our offer includes automation for the doors of the leading manufacturers: Somfy, Beninca and GfA Eletromaten.

Door panels

The door panels are available in two finishes: the smooth SLICK and WOODGRAIN, which mimics the structure of the wood.

Examples of garage door designs

Panel without embossing

garaazivaravad 01 panel bez przetloczen winchester

Winchester colour door

garaazivaravad 01 drzwi t50s29 winchester

T50 S29 colour door

garaazivaravad 01 panel bez przetloczen antracyt ciemny

Door in dark anthracite colour

garaazivaravad 01 drzwi t53s37antracyt ciemny

T53 S37 door in dark anthracite colour

Available colours

dark anthracite (slick)

golden oak (slick)

dark walnut (slick)

marsh oak (slick)

garaazivaravad 01 antracyt drewnopodobny

woodlike anthracite (slick)

winchester (slick)

Available colours

garaazivaravad 02 panel z waskim tloczeniem bialy woodgrain

White door (woodgrain)

T46 S35 door in white, embossed

Available colours

brown (woodgrain)

white (woodgrain)

Wide embossing panel

garaazivaravad 03 panel z szerokim tloczeniem zloty dab slick

Gold oak door (slick)

T41 S37 door gold oak

Available colours

golden oak (slick)

dark walnut (slick)

Additional execution options

garaazivaravad 04 opcja brama z drzwiami przejsciowymi i niskim progiem

with pass-through door and low sill

garaazivaravad 04 opcja brama z drzwiami przejsciowymi i wysokim progiem

with pass-through door and high sill

window panel

garaazivaravad 04 opcja panel z sekcja aluminiowa

panel with aluminium section

Design of sectional garage doors

Standard equipment

Door made of 40 mm thick panels filled with polyurethane foam finished with galvanized laminated steel sheet
Support frame – angles and guides made of galvanized steel profiles with a thickness of 2 mm
Front torsion springs with standard number of cycles equal to 15000
Central and side hinges made of galvanized steel sheet

Thermal conductivity

Panels used in the production of our doors are characterized by thermal insulation parameter at the level of Ud=0.74 W/(m²*K)

Standardne kasutusohutus

A safety mechanism to prevent the door from falling down in the event of a spring breakage
Secure-lock panels prevent fingers from accidental pinching
Profiled guides protect the rollers from falling out
The Omega trapezoid reinforcement prevents panels longer than 5m from bending
Amperometric obstacle detection system – used to detect possible obstacles that may occur during the normal movement of the door. Thanks to this function, when an obstacle is encountered, the drive stops the door and changes the direction of its movement.

garaazivaravad 05 panele z bezpiecznym zamkiem

Leading

Door with front lead guide

Rear lead guided door

Table of markings for the dimensions of sectional garage doors

Width of the opening, ordering dimension		S_O
Hole height, ordering dimension		H_O
Entrance lumen height		H_W	H_O - 150 mm
Entry lumen width		S_W	S_O
Minimum required lintel height		N
Front guide, front springs (at lintel)	Manual door	N	200 mm
	Automated door
Minimum depth of the room with free space under the ceiling		D	H_O + 500
Minimum width of the left lateral space		B_L	80 mm
Minimum width of the right lateral space		B_R	80 mm
Length of door guide		L_P	2900 или 3500
Drive guide length		L_PN	3200 или 3800

Doors ordering – it’s so simple!

Fill out the form on our website and we will contact you.

We will make measurements at a convenient time for you.

We will make you a price offer: the transaction is transparent and specific. No additional fees or hidden costs.

We make doors.

We deliver and install doors ordered by you.

* A trip to Tallinn to take measurements cost: 20€ + VAT. Trips outside Tallinn cost 1,5 € + VAT per kilometer.
